At Kalyros Engineering LLP, we design and manufacture high-performance filter elements engineered to ensure purity and efficiency of fluid and air systems across industries. Our elements remove contaminants from liquids and gases, protecting machinery and improving operational reliability. Built for precision and durability, our filters are configurable to suit diverse application needs.

Overview

Kalyros Engineering LLP proudly manufactures high-performance filter elements designed to ensure the purity and efficiency of fluid and air systems across various industries. These filter elements are critical components that remove contaminants from liquids or gases, protecting machinery and enhancing operational reliability. Crafted with precision and durability in mind, our filter elements are tailored to meet diverse application needs.

Manufacturing Process

• Material Selection and Preparation – High-quality filter media (e.g., cellulose, synthetic fibers, or metal mesh) and end caps (e.g., steel or plastic) are chosen based on filtration needs. Media is precision-cut and prepared.
• Pleating – Media is pleated using automated pleating machines to increase surface area and filtration efficiency, ensuring uniform folds and optimal contaminant capture.
• Assembly – Pleated media is formed into cylinders and secured between metal or plastic end caps. Adhesives or mechanical seals ensure a tight, bypass-free fit.
• Core and Support Structure Installation – A perforated metal/plastic core is inserted to provide structural support; an outer support cage is added when required.
• Sealing and Bonding – End caps are bonded by heat sealing, adhesives, or ultrasonic welding for leak-proof assembly. Gaskets or O-rings are added as needed.
• Quality Control and Testing – Each element undergoes pressure testing, flow-rate analysis, and contaminant-retention tests (e.g., ISO 2941). Visual inspections verify pleat and seal integrity.
• Packaging – Finished elements are cleaned, dried, and packaged in protective materials to avoid contamination during transport.

How It Works

Fluid or air passes through the pleated media, which traps contaminants while allowing the clean fluid to pass. Pleats increase surface area for better retention; the support core keeps shape under pressure. Flow is typically from the outer surface toward the inner core, capturing particulates and protecting downstream equipment.

Applications and Uses

• Automotive – Oil and fuel filters for engines to remove contaminants and extend life.
• Refrigeration – Air/refrigerant filters in cooling equipment to maintain efficiency.
• Air Conditioning – HVAC filters to remove dust and allergens for clean circulation.
• Industrial Machinery – Hydraulic and lubrication system filters for manufacturing plants.
• Oil & Gas – Gas and liquid filtration in refineries and pipelines for process purity.
• Medical Equipment – Air filters in ventilators and sterilizers for sterile environments.
• Food & Beverage – Liquid filtration in processing lines to maintain product safety.
• Power Generation – Air intake filters for turbines and generators to prevent debris damage.

Materials and Grades

Our filter elements are available in multiple media and grades:

• Cellulose – Cost-effective, general-purpose oil and air filtration.
• Synthetic Fibers (Polyester, Polypropylene) – High efficiency, water- and chemical-resistant.
• Glass Fiber – Superior filtration for fine particulates and high-performance needs.
• Stainless Steel Mesh – Durable, reusable, suited for high-temperature or corrosive fluids.
• Composite Materials – Multi-media constructions for enhanced longevity and performance.

Grades are expressed in micron ratings (e.g., 1–100 µm) and tailored to contaminant size and flow requirements.

Types of Filter Elements

• Cartridge Filters – Cylindrical elements for high-flow applications.
• Panel Filters – Flat or pleated panels for HVAC and air purification.
• Bag Filters – High-capacity filters for industrial liquid filtration.
• Spin-On Filters – Integrated housing and element for easy replacement (automotive use).
• Pleated Filters – Compact designs with increased surface area for high efficiency.

Additional Features and Benefits

• Customization – Sizes, micron ratings, and configurations to match specific needs.
• Durability – Robust construction for long service life under demanding conditions.
• Efficiency – High contaminant removal rates to protect equipment and improve system performance.
• Ease of Maintenance – Designed for quick replacement to minimize downtime.

Why Choose Kalyros Engineering LLP?

• Commitment to Quality – Manufactured to meet global standards and industry best practices.
• Advanced Manufacturing – Modern facility and processes for consistent results.
• Material Expertise – Wide selection of media and construction methods for optimal performance.
• Customer Support – Consulting, customization, and after-sales service to meet project requirements.

Contact & Custom Orders

For custom sizes, micron ratings, or application-specific designs, contact our sales team to discuss requirements and request a quote. Kalyros Engineering LLP delivers filtration solutions tailored to your process needs.

---

Whether you need filtration for automotive systems, industrial machinery, or critical process equipment, Kalyros Engineering LLP provides reliable, efficient filter elements engineered for performance and longevity.
